| Model | ZK-30T |
| Operating weight | 3000kg |
| Bucket Capacity | 0.075m³ |
| Engine | Changchai 390 |
| Power | 20kw |
| Distance from ground to upper panel | 534mm |
| Front and rear wheelbase | 1560mm |
| Left-right gauge | 1200mm |
| Boom deflection | 45°(left) |
| Boom deflection | 55°(right) |
| Overall length | 3074mm |
| Overall width | 1500mm |
| Overall height | 2313mm |
| Tail swing radius | 936mm |
| Minimum ground clearance | 230mm |
| Hydraulic system pressure | 18Mpa |
| Maximum excavation force of the bucket | 195KN |
| Numbers of thrust wheel per side | 3 pieces |
| Numbers of track wheels per side | 1 pieces |
