1.Hydraulic power steering wheel for easy operation.
2.Flange Cylinder,good sealing, stable connection.
3.LED lighting, high brightness, energy saving.
4.Cast steel axle, strong bearing capacity.
5.Electrophoretic anti-rust spray paint.
6.Backhoe bucket, work like an excavator.
| Model | JG 40-28 |
| Overall Operating Weight | 8000kg |
| Dimension | 6120×2410×3763mm |
| cab to ground | 2900mm |
| Wheelbase | 2248mm |
| Min. Ground Clearance | 300mm |
| Bucket Capacity | 1m³ |
| Breakout Force | 38KN |
| Loading Lifting Capacity | 2500kg |
| Bucket Dumping Height | 2700mm |
| Bucket Dumping Distance | 925mm |
| Digging Depth | 52mm |
| Backhoe Capacity | 0.3m³ |
| Max. Digging Depth | 3800/4500mm |
| Swing Angle of Excavator Grab | 190° |
| Max. Pulling Force | 39KN |
| Engine | Yunnei YN48GBZ |
| Rated Power | 92kw |
| Rated Speed | 2200r/min |
| Min. turning radius | 6581mm |
| Gearbox | Fixed Shaft Power Transmission |
| Gears | 2F+2R |
| Max.Speed | 28Km/h |
| Tire | 14-17.5/19.5L-24 |
If you have any questions, please leave a message, we will reply as soon as possible.
