| Model | ZK-800 |
| Machine weight without attachment | 1069kg |
| Bucket weight | 80kg |
| Tipping load | 416kg |
| Track width | 200mm |
| Ground pressure | 0.261 |
| Max Speed | 5.6km/h |
| Angle of departure | 28° |
| Minimum height of bucket pin from ground | 163mm |
| Dumping angle at maximum height | 30° |
| Dumping height | 1685mm |
| Dumping reach | 610mm |
| Ground clearance | 258mm |
| Foot pedal clearance | 270mm |
| Height to bucket hinge pin | 2160mm |
| Height of machine | 1400mm |
| Without bucket length | 2160mm |
| Overall length with bucket | 2830mm |
| Overall operating height | 2800mm |
| Rollback o bucket on ground | 39° |
| Rollback of bucket at full height | 69° |
| Tread width | 1150mm |
| Front turning radius without bucket | 1495mm |
| Width | 1006mm |
| Track gauge | 830mm |
| Bucket width | 1235mm |
