| Vehicle (length*width*height) | 2200*1100*1300 | engine | Changzhou 192/195 Power: 13.2kw |
| Carrying weight (kg) | 1500 | Cargo box size | 1350*1100*500 |
| Track specifications | 2300*720*460 | Vehicle mass (kg) | 730(optional crane) |
| Dump function | Hydraulic dump | Track material | Engineering steel wire rubber tracks |
| top speed | 12km/h | Start mode | Electric start/hand pull |
| Standing slope angle | 35° | operating lever | 3F+1R |
| Cargo box height from the ground (cm) | 50 | uphill angle | 45° |
| Shaft material | Precision steel pouring and heat treatment | Minimum turning radius (m) | 1.5 |
| wheel material | Precision cast steel | gearbox | Guli brand 18 |
